SWAN by S&S
1972-1975 - S&S des. #2112 - 76 hulls built
GENERAL DIMENSION
| Loa: | 44.09 ft | 13.48 m |
| Lwl: | 33.89 ft | 10.33 m |
| Beam: | 12.58 ft | 3.83 m |
| Draft: | 7.4 ft | 2.3 m |
| Ballast: | 12600 lbs | 5140 kg |
| Displacement: | 28000 lbs | 12700 kg |
| Antifouled area: | 473 ft² | 44 m² |
ON BOARD SYSTEMS
| Fuel: | 39.6 gal(US) | 150 l |
| Fresh water: | 87.1 gal(US) | 330 l |
| Service power: | 12 v, 210 ah | |
| Engine: | Perkins 4.108M 37 hp at 3000 rpm |
|
SAIL PLAN
Short rig
| I: | 55 ft | 16.76 m |
| J: | 18.6 ft | 5.67 m |
| P: | 48.5 ft | 14.78 m |
| E: | 15 ft | 4.57 m |
| Fore triangle: | 511.5 ft² | 47.5 m² |
| Main: | 363.89 ft² | 33.8 m² |
| Genoa 150%: | 767.2 ft² | 71.3 m² |
| Spinnaker: | 1841 ft² | 171 m² |
Tall rig
| I: | 57.5 ft | 17.53 m |
| J: | 18.6 ft | 5.67 m |
| P: | 51 ft | 15.54 m |
| E: | 15.5 ft | 4.72 m |
| Fore triangle: | 534.7 ft² | 49.7 m² |
| Main: | 395.3 ft² | 36.7 m² |
| Genoa 150%: | 802.1 ft² | 74.5 m² |
| Spinnaker: | 1925 ft² | 179 m² |
